HT7350 regulator (Pack of 2)

£1.00

40 in stock

SKU: HT7305 Category:

Description



Low Dropout Regulators(LDO) Positive Fixed 60mV @ 40mA (typ) 12V 5V 250mA SOT-89(SOT-89-3) RoHS

Low Power Consumption LDO
The HT73XX Series is a Set of Three-terminal, Low Power, High Voltage Regulators Implemented in CMOS Technology.
The Series Features Extremely Low Quiescent Current Which is Typically 4mA. They Allow Input Voltages as High as 12V. The Device Provides Large Current With a Significantly Small Dropout Voltage.
The HT73XX Consists of a High-precision Voltage Reference, an Error Correction Circuit, And a Current Limited Output Driver. They Are Available With Several Fixed Output Voltages Ranging From 1.8V to 5.0V. CMOS Technology Ensures Low Dropout Voltage And Low Current Consumption. Although Designed Primarily as Fixed Voltage Regulators, These Devices CAN be Used With External Components to Generate Variable Voltages And Currents.

Features
Ultra Low Quiescent Current: 4mA (typ.)
High Input Voltage (up to 12V)
Output Voltage: 1.8V, 2.5V, 2.7V, 3.0V, 3.3V, 3.5V, 5.0V
Output Voltage Accuracy: Tolerance 3%
Maximum Output Current: 250mA
Low Dropout Voltage
Low Temperature Coefficient
TO-92, SOT-89 Package

Additional information

Weight 0.003 kg
